PressureStream – Modular, Customizable Wall Fans

The PressureStream is a power ventilation system used for warm air roof exhaust or cool air supply into a building. This modular, customizable fan is ideal for sidewall mounting for supply air. In this configuration, the PressureStream is the key component for any Pressure Gravity System®.  Here are some of the features, uses, and benefits of the PressureStream:

Modern Propeller Blades

The PressureStream features modern propeller blades with sophisticated airfoil shaped designs. They are made with fiber-reinforced thermoplastic with a helical twist. The unit is powered by a direct-drive motor to avoid the hassle of fan belts.

The most common PressureStream fan utilizes a 3 HP, 1160 RPM motor capable of 20,000 CFM. Each unit is airflow performance modeled and tests are conducted in accordance with parameters of ANSI / AMCA 210-99 (ISO 5801, DIN 24163). These features ensure that the unit is able to function at maximum efficiency for an extended duration.

Durable and Strong Propeller Hubs & Housing

industrial wall fan in natural gasIn addition, the standard propeller hubs of the PressureStream are manufactured using high-strength die-cast aluminum. The housings are made with high-quality G90 galvanized steel.

These give the equipment its durability and strength. You can be assured that they will serve your industrial exhaust and power ventilation needs for many years to come.

Product Mounting

Lastly, the intake PressureStream is mounted directly into the sidewall. They are often fitted with rain hoods to prevent water from entering. As it uses the exhaust side of the fan, air can travel a distance equal to 5 times the diameter of the fan. This ensures the cool, clean supply air flows directly into the working environment. In the end, this results in a cooler and more comfortable space for employees or factory workers.

The Moffitt PressureStream

At Moffitt Corporation, we have power ventilation fans available in a wide variety of sizes and motor horsepower configurations. These units can also be designed or customized for your specific commercial or industrial application. Contact us today to learn more about our PressureStream unit and other wall exhaust fan equipment. No matter your power ventilation needs, Moffitt has you covered.
